The AD7306 is a +5 V powered RS-232/RS-422 transceiver from Analog Devices. It features single +5 V supply, 0.1 µF capacitors, short circuit protection, excellent noise immunity, low power BiCMOS technology and high speed, low skew RS-422 operation. It is suitable for applications such as DTE-DCE interface, packet switching, local area networks, data concentration, data multiplexers, and Integrated Services Digital Network (ISDN).
The AD7306 is a 5 V monolithic line driver/receiver that provides an interface between TTL levels and dual‑standard RS‑232/RS‑422 signal levels. It includes two RS‑232 drivers, one RS‑422 driver, one RS‑232 receiver and a configurable RS‑422/RS‑232 receiver, all powered from a single +5 V supply using an internal charge‑pump that generates ±10 V.
The document provides electrical specifications, pin‑out tables for the 24‑lead SOIC and 24‑pin DIP packages, typical performance curves, and application notes on single‑ended and differential data transmission. Ordering information for temperature‑rated variants is also included.
