ADG3308/ADG3308-1 are bidirectional level translators containing eight bidirectional channels. They can be used in multivoltage digital system applications. Features include bidirectional logic level translation, operating voltage range of 1.15V to 5.5V, low quiescent current <1μA, etc.
The ADG3308 is an 8‑channel bidirectional logic level translator from Analog Devices, designed to translate signals between low‑voltage ASICs and higher‑voltage devices.
It operates from 1.15 V to 5.5 V, draws less than 1 pA quiescent current, and supports data rates up to 50 Mbps. The device is offered in several compact packages including 20‑lead TSSOP, LFCSP and wafer‑level chip‑scale packages.
| Supply Voltage Range | 1.15 V to 5.5 V |
|---|---|
| Number of Channels | 8 |
| Quiescent Current | <1 pA |
| Temperature Range | -40°C to +85°C |
| Maximum Data Rate | 50 Mbps |
| Package Options | 20‑lead TSSOP, 20‑lead LFCSP, 20‑ball WLCSP, backside‑coated 20‑ball WLCSP |
The ADG3308 operates from 1.15 V to 5.5 V.
It provides eight bidirectional channels.
No, the device has no direction pin.
The device supports data rates up to 50 Mbps.
