M81709FP is a high voltage power MOSFET and IGBT module driver for half bridge applications, suitable for PDP, HID lamp, refrigerator, air-conditioner, washing machine, AC-servomotor, and general purpose.
The M81709FP is a high‑voltage half‑bridge driver designed for MOSFET and IGBT module inverter applications such as PDP, HID lamps, refrigerators, air‑conditioners, washing machines, AC‑servomotors, and general‑purpose use.
It operates with a floating supply voltage up to 624 V, delivers up to 2 A output current, and is supplied in a 16‑pin SOP package. Features include under‑voltage lockout, level shifting, UV detection, and detailed timing behavior, with full electrical characteristics and package dimensions listed.
| Floating Supply Voltage (VB) | 0.5 ~ 624 V |
|---|---|
| Output Current | 2 A |
| Package | SOP‑16 (16‑pin plastic) |
The device can handle a floating supply voltage from 0.5 V up to 624 V.
It is supplied in a 16‑pin SOP (plastic) package.
The driver can source up to 2 A of output current.
