This document mainly introduces the application of IPM and the characteristics and advantages of ST's DIPIPMTM series products
The document introduces Mitsubishi Electric's power semiconductor portfolio, covering power modules such as diodes, thyristors, IGBTs and intelligent power modules (IPM). It highlights the series' low‑loss, energy‑saving designs, high insulation voltage (1500 V‑3500 V) and a wide range of current ratings for various industrial and consumer applications.
Detailed sections describe the Dual‑In‑Line Package Intelligent Power Modules (DIEIPM), Super Mini and Mini DIPIPM families, and Large DIPIPM series, noting features like RoHS‑compliant lead‑free terminals, UL1557 certification, and built‑in protection circuits (over‑current, over‑voltage, UV). The manual also outlines typical uses in HVAC, UPS, motor drives, renewable energy and automotive systems. This manual is written in Chinese.
| Insulation voltage | 1500 V‑3500 V |
|---|---|
| Current rating (600 V series) | 3 A‑75 A |
| Current rating (1200 V series) | 5 A‑35 A |
| Safety certification | UL1557 |
| RoHS compliance | Lead‑free terminals |
The modules are designed for insulation voltages between 1500 V and 3500 V.
The series offers 3 A to 75 A at 600 V and 5 A to 35 A at 1200 V.
Yes, they meet the UL1557 safety certification.
Yes, the external terminals are lead‑free to satisfy RoHS requirements.
