This document is a user manual for the S310 series 220V level 0.4~1.5KW (0.88~2.9KVA) VER:04 2010.1. It provides information on safety precautions, model specifications, usage environment and installation, software index, troubleshooting and maintenance for using IGBT to drive AC motors.
This manual covers the safe operation of the Taian S310 series variable frequency drive, including pre‑installation checks, wiring requirements, and environmental limits. It also details the control panel layout, parameter settings, and how to connect peripheral devices such as braking resistors and communication modules.
The document provides a comprehensive troubleshooting guide, maintenance procedures, and a full list of technical specifications such as input voltage, rated power, current limits, and operating temperature ranges. Appendices include wiring diagrams and parameter tables for quick reference. This manual is written in Chinese.
| Input voltage | 200‑240 V |
|---|---|
| Output voltage | 200‑240 V |
| Rated power | 0.4 kW ~ 1.5 kW |
| Rated current | 3.1 A ~ 7.5 A |
| Rated capacity | 0.88 kVA ~ 2.9 kVA |
| Operating temperature | -10 °C ~ +40 °C |
