This document provides an overview of the PLC composition, including the features and characteristics of various models of products, as well as different programming methods. It mentions products such as TP03 M, TP03 H, and TP03 SR, and their input/output points, storage capacity, and expandable modules.
This manual describes the TP03 PLC controller family, including the M, H and SR types. It outlines the controller’s architecture, flash memory capacity, I/O point limits, and the expandable input‑output modules.
The document also explains programming methods (LD, AND, OUT), parameter configuration via PC/PDA LINK, and the operation of timers, counters, and data registers. Safety notes and maintenance procedures are included for service technicians. This manual is written in Chinese.
| Flash memory (M type) | 8,000 steps |
|---|---|
| Flash memory (SR type) | 4,000 steps |
| Maximum digital input points (H type) | 256 points |
| Expandable I/O modules (M type) | 8 input modules, 2 output modules |
| Parameter configuration interface | PC/PDA LINK |
The TP03 M type contains 8,000 steps of flash memory.
The TP03 H type can handle up to 256 digital input points.
Parameters are set through the PC/PDA LINK communication interface.
