G3VM-402J is a MOS FET driver from OMRON. Its main features are an output current of 120mA, a load voltage of 400V, and a working temperature range of -20℃ to 65℃.
The G3VM-402J is an MOS FET relay designed for switching analog signals. It supports a load voltage up to 400 V and offers high isolation between input and output.
The manual includes electrical characteristics, recommended operating conditions, wiring diagrams, and LED indicator specifications to ensure correct operation and reliable reset of the relay. This manual is written in Chinese.
| Input‑output isolation voltage | 1500 Vrms |
|---|---|
| LED forward current (typical range) | 5–25 mA |
The input‑output isolation voltage is rated at 1500 Vrms.
