Provides a list of D3V small basic switch product models.
The D3V series are small basic switches offered by Omron with current ratings of 0.1 A, 6 A, 11 A, 16 A and 21 A. They comply with EN61058‑1 and UL1054 and are available with external or internal levers, various mounting options, and high‑temperature versions (125 °C).
The document details proper mounting using two M3 screws, required torque (0.39–0.59 N·m), minimum insulation distance (9 mm), and handling precautions for the low‑load design. It also includes wiring diagrams, terminal codes, and guidance on using protective circuits for surge loads. This manual is written in Chinese.
| Rated Voltage | 250 VAC |
|---|---|
| Maximum Operating Force | 0.49 N |
| High‑Temperature Version | 125 °C |
It complies with EN61058‑1 and UL1054.
