G3VM-401H is a MOS FET relay produced by Panasonic. It is suitable for analog signal switching. The load voltage is 400V and the continuous load current is 120mA. The input and output withstand voltage is 1500Vrms.
The G3VM-401H is a MOS‑FET type relay designed for 400 V series applications. It offers a compact surface‑mount package with a 2.54 mm pin pitch and includes an indicator LED for status monitoring.
Key specifications include a maximum AC voltage rating of 400 V (1500 Vrms withstand), a load current of 120 mA, operating temperature range from –40 °C to 85 °C, and LED forward voltage of 1.0‑1.8 V. The manual also lists terminal capacitance (30 pF) and other electrical performance data. This manual is written in Japanese.
| Maximum AC voltage rating | 400 V |
|---|---|
| Withstand voltage | 1500 Vrms |
| Maximum load current | 120 mA |
| Operating temperature range | -40 °C to 85 °C |
| Terminal capacitance | 30 pF |
| LED forward voltage | 1.0‑1.8 V |
| LED forward current | 1‑3 mA |
| Maximum switching voltage | 500 VDC |
The relay is rated for 400 V AC, with a withstand voltage of 1500 Vrms.
The maximum load current is 120 mA.
It can operate from –40 °C to 85 °C.
The LED forward voltage is between 1.0 V and 1.8 V.
