G7L series power relay has the characteristics of high capacity, high voltage resistance and strong anti-sudden voltage drop performance.
This manual describes the G7L series power relays, covering model structures, electrical characteristics, and recommended applications such as compressors, motor control, and lighting. It includes detailed installation methods for terminal‑type, screw‑terminal, and surface‑mount adapters, as well as wiring diagrams and mounting dimensions.
Key performance data such as rated current, coil voltage ranges, contact spacing, and environmental limits are listed, along with test results for impact resistance, voltage drop, and load life. Certification information and material compliance are also provided. This manual is written in Chinese.
| Contact spacing | 3 mm |
|---|---|
| Insulation material | UL94V‑0 flame‑retardant |
| Switching cycles rating | 1 800 cycles/h |
The contact spacing is 3 mm.
The relay is rated for up to 1 800 switching cycles per hour.
