Delta DVP‑SX2 Installation Guide

This manual introduces the functions, features and usage methods of DVP-SX2.


Delta DVP‑SX2 Installation Guide - cover page
Brand
AELTA
Document type
Installation Guide
Language
English
Pages
20
File format
PDF
File size
968 KB
Published
16 March, 2012
Updated
30 September, 2023
MD5 checksum
4FED6817806C204857B5A6F50D0736A2

About this manual

The guide covers the DVP‑SX2 PLC’s electrical specifications, including power requirements, input/output configurations, and analog/digital module data. It also details safety precautions, grounding, and environmental limits for reliable operation.

Installation instructions describe proper mounting on DIN rails or direct fixing, wiring recommendations for I/O terminals, and RS‑485 communication setup. Reference tables and diagrams illustrate the PLC’s front‑panel layout, connector pinouts, and wiring diagrams for both relay and transistor output models.

What's inside

  • Product Profile
  • Electrical Specifications
  • Input Point Specifications
  • Output Point Specifications
  • A/D and D/A Specifications
  • I/O Configuration
  • Dimension & Installation
  • Wiring
  • RS‑485 Wiring
  • Safety Wiring

Specifications

Power supply voltage24VDC (-15% ~ 20%)
Power consumption (R version)4.7W
I/O points8DI + 6DO + 4AI + 2AO
Maximum I/O expansion points480
High‑speed pulse output frequency100 kHz (2 groups)
Weight (R version)243 g

Frequently asked questions

What wire gauge should be used for I/O wiring?

Use 22‑16 AWG (1.5 mm) single or multi‑core wire on I/O terminals.

How do I mount the PLC on a DIN rail?

Pull down the retaining clip, place the PLC onto the rail, and gently push the clip up to lock it.

Which power supply modules are recommended for the DVP‑SX2?

Delta DVPPS01 or DVPPS02 power supply modules are suitable.

What is the operating temperature range of the PLC?

The PLC operates from 0 °C to 55 °C.

Download PDF (968 KB)
