DVPCOPM-SL is an open-type device in compliance with CANopen standard protocol DS301v4.02
The DVPCOPM‑SL is a CANopen communication module that connects to a PLC MPU. It operates on a 24 VDC bus and supports up to eight modules in a network. The manual provides wiring diagrams, power specifications, and configuration steps.
Key sections cover LED status indicators, error troubleshooting, address setting via DIP switches, and communication speed settings ranging from 10 kbps to 1 Mbps. Environmental and electrical isolation requirements are also listed. This manual is written in Chinese.
| Power supply voltage | 24 VDC ±5 % |
|---|---|
| Maximum RxPDOs | 200 |
| Maximum modules per network | 8 |
