This document provides instructions for the installation, wiring, inspection, and operation of Delta ASDA-B series AC servo drive and ECMA series servo motor. It is important to read and understand this document before using the product to ensure correct use. If you have any questions, please contact your local Delta sales representative. Keep this document in a safe place for future reference.
This quick start guide provides safety precautions, unpacking checks, and step‑by‑step instructions for installing and wiring Delta ASDA‑B series AC servo drives together with ECMA series servo motors. It emphasizes proper grounding, correct connection of power and encoder cables, and the need for qualified personnel during installation and maintenance.
The document also covers storage conditions, minimum clearances, cable specifications, and basic inspection procedures before and during operation. It includes tables of drive‑motor power combinations, wiring methods for three‑phase and single‑phase supplies, and recommended cable types to minimize noise and interference.
| Maximum ground resistance | 100 Ω |
|---|---|
| Encoder feedback cable maximum length | 20 m |
| Command input cable maximum length | 3 m |
| Storage temperature range | -20 °C to +65 °C |
| Storage relative humidity range | 0 % to 90 % |
The ground resistance should not exceed 100 Ω.
The encoder feedback cable can be up to 20 m long.
Store the drive in a clean, dry location between –20 °C and +65 °C.
