WJ-ND200 is a pure IP network hard disk recorder that supports MPEG-4 and JPEG formats. It can record up to 16 IP cameras, supports two 2.5-inch removable hard drives, and supports various recording functions, including scheduled recording, emergency recording, external timer recording, and event recording.
This manual covers the features and operation of the Panasonic WJ‑ND200 VCR, including support for MPEG‑4 and JPEG video formats, a removable 2.5‑inch hard drive with RAID‑1 capability, and network connectivity via 10Base‑T/100Base‑TX RJ45. It also explains how to connect up to 16 cameras, configure image resolution up to 1280 × 960, and use external ports such as the 25‑pin D‑sub for alarm and control signals.
Technical specifications are listed, such as power requirements (AC 220‑240 V, 50 Hz, 35 W), physical dimensions (270 mm W × 88 mm H × 360 mm D), weight (5 kg), and supported network speed (48 Mbps). The manual also details system logging, external alarm handling, and compatible operating systems (Windows 2000/XP). This manual is written in Japanese.
| Supported video formats | MPEG‑4, JPEG, M‑JPEG |
|---|---|
| Hard drive type | Removable 2.5‑inch |
| Maximum cameras | 16 |
| Maximum image resolution | 1280 × 960 |
| Network interface | 10Base‑T/100Base‑TX RJ45 |
| Network speed | 48 Mbps |
| Power supply | AC 220‑240 V, 50 Hz |
| Dimensions (W × H × D) | 270 mm × 88 mm × 360 mm |
| Weight | 5 kg |
The device can handle up to 16 cameras simultaneously.
It supports a removable 2.5‑inch hard drive that can be swapped without powering down the main unit.
The VCR includes a 10Base‑T/100Base‑TX RJ45 Ethernet port.
It operates on AC 220‑240 V, 50 Hz and consumes about 35 W.
