The WV-CS570 series is a compact, color CCTV camera with 22x optical zoom lens and integrated tiny pan-tilt unit. The camera features 510 lines of horizontal resolution, 0.03Lux SENS UP sensitivity and 32 preset positions.
The Panasonic WV‑CS570 series is an integrated color security camera with a compact 110 mm housing, a 22× optical zoom lens and a small high‑speed PTZ unit. It delivers 510‑line horizontal resolution and can operate in very low light down to 0.03 Lux.
The camera supports up to 32 preset positions, 360° continuous horizontal rotation, 180° vertical tilt, and features such as privacy masking, patrol learning, digital motion detection, and image hold during rapid movement. Power options are AC 220‑240 V or AC 24 V, with a typical consumption of 15 W. This manual is written in Chinese.
| Effective Pixels | 752(H) x 582(V) |
|---|---|
| Horizontal Resolution | 510 lines (HIGH mode) |
| Minimum Illumination | 0.03 Lux (SENS UP mode) |
| Power Consumption | 15 W |
| Weight | ≈ 2 kg |
| Dimensions | 6120 mm × 191 mm |
The camera can store up to 32 preset positions.
The minimum illumination is 0.03 Lux in SENS UP mode.
It offers a horizontal resolution of 510 lines in HIGH mode.
