WJ-ND300A is a Panasonic i-Pro series network hard disk recorder that can record 32 IP cameras. Supports MPEG4 and JPEG formats and has a wealth of timing, event, emergency, external timer functions.
The WJ‑ND300A is a network video recorder that can record video from up to 32 IP cameras, supporting MPEG‑4, JPEG and M‑JPEG formats. It offers high‑quality imaging, multiple recording modes, and extensive alarm and event functions, with optional RAID5 expansion for larger storage.
The manual details supported image resolutions (up to 1280 × 960), maximum frame rates (30 fps per camera), network interfaces (10/100 Mbps Ethernet), power consumption (≈85 W), and environmental limits. It also describes system configuration, user management, and compatible software and browsers. This manual is written in Chinese.
| Maximum number of cameras | 32 |
|---|---|
| Maximum frame rate per camera | 30 fps |
| Maximum storage capacity | 14 TB |
| Power consumption (typical) | 85 W |
| Operating temperature range | -5 °C to 45 °C |
| Maximum network bandwidth | 97 Mbps |
| Supported network protocols | TCP/IP, UDP, HTTP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, RTP |
It can connect up to 32 IP cameras.
The recorder supports manual, scheduled, emergency, external timer, and time‑based recording modes.
Yes, adding the optional RAID5 panel (WJ‑NDB301) enables RAID5 functionality and allows up to 14 TB of storage.
