The WV-NP240 series is a network color camera of the Panasonic i-Pro series, which has MPEG-4 and JPEG digital signal output, MPEG-4 and JPEG dual-stream output, Ethernet power supply (PoE) function, progressive scan CCD image sensor, network protocol, image refresh rate, communication control, built-in network interface, minimum illumination, built-in SD memory card slot for FTP backup, multi-screen display, built-in alarm function, built-in digital motion detector, built-in electronic zoom function, automatic electronic sensitivity enhancement, built-in microphone (G.726).
This manual describes the key features of the Panasonic WV‑N240 series camcorder, including its progressive‑scan CCD sensor, dual MPEG‑4/JPEG output, PoE power support, and built‑in alarm functions. It also provides information on image settings such as electronic zoom, automatic gain control, and low‑light performance.
Technical specifications are listed, covering video output connectors, network interfaces, power consumption, dimensions, and environmental operating ranges. The document includes guidance for remote monitoring via Ethernet and FTP backup using SD cards. This manual is written in Chinese.
| Model | WV‑N240 |
|---|---|
| Image Sensor | 1/3‑type progressive‑scan CCD |
| Effective Pixels | 659 (H) × 494 (V) |
| Minimum Illumination (Color) | 0.7 Lux |
| Video Output | Composite (3.5 mm jack) |
| Network Interface | 10Base‑T/100Base‑TX RJ45 |
| Weight | ≈470 g (≈450 g for PoE version) |
The minimum illumination in color mode is 0.7 Lux (SENS UP mode 0.04 Lux).
It uses a 1/3‑type progressive‑scan CCD sensor.
