The Casio IT-500 data collector is a handheld computer from Casio. It features the latest handheld computer microprocessor, an integrated laser scanner, a wireless network card, and a WinCE 4.1 operating platform, giving you powerful expansion capabilities for use in any business setting.
The Casio IT-500 is a pocket‑sized handheld computer designed for commercial and logistics use. It features an integrated laser scanner, a color TFT display, and runs on Windows CE 4.1, offering a robust platform for data capture and wireless communication.
The device supports IEEE802.11b Wi‑Fi, Bluetooth, and includes a rechargeable Li‑ion battery. It meets IP54 dust‑and‑water protection, operates from 10 °C to 50 °C, and can scan a variety of 1‑D barcodes over a 40 mm‑300 mm range. This manual is written in Chinese.
| Processor | IntelePXA255 Application Processor (400 MHz) |
|---|---|
| Memory | 64 MB user area |
| Scan Distance | 40 mm – 300 mm |
| Minimum Resolution | 0.127 mm |
| Supported Barcode Types | EAN, UPC, NW7/Codabar, ITF, Code39, Code93, Code128, MSI/Plessy, IATA |
| Display | 3.5‑inch 2‑way TFT true‑color LCD |
| Battery | Rechargeable Li‑ion battery (standard capacity) |
| Weight (wireless model) | 260 g |
| Operating Temperature | 10 °C – 50 °C |
| Storage Temperature | -20 °C – 60 °C |
| IP Rating | IP54 |
It runs Windows CE 4.1.
The device meets the IP54 dust‑ and water‑proof standard.
It can scan barcodes from 40 mm up to 300 mm.
