Featured Shanghai条码网 manuals
Shanghai Barcode Network Symbol LS2208AP Barcode scan Implement Manual
The Symbol LS2208hAP barcode scanner is a handheld laser device featuring a 650 nm visible laser diode and a scanning range up to 8 inches (20 cm) for 100 % UPC/EAN codes. It operates at 100 scans per second with a scan angle of ±30°, front/back swing of ±65°, and left/right swing of ±60°.
The scanner supports multiple interfaces (USB, RS232, Keyboard Wedge, etc.) and can be programmed via RS232 or the included software. It is rated for indoor and outdoor use, operates from 0 °C to 50 °C, stores from –40 °C to 70 °C, and meets various regulatory standards (L, CSA, VYDE, FCC). This manual is written in Chinese.
Covers: Basic Parameters · Scanning Performance · Power Requirements · Physical Characteristics · Interface Options · Environmental Ratings
Ring 4012PMH Barcode Printer Manual
The Ring 4012PMH is a steel‑structured industrial barcode printer offering 300 dpi resolution and a maximum print speed of 152 mm/s. It supports both thermal transfer and direct thermal printing, with a print width up to 104 mm and a weight of 9 kg.
The manual details the printer’s memory (16 MB DRAM, 4 MB Flash ROM), communication options (RS‑232 and standard parallel port), penetrating label sensor, supported barcode symbologies, and a wide range of printable media such as continuous thermal paper, label rolls, UL labels, transparent and water‑washable papers. This manual is written in Chinese.
Covers: Printing Method · Resolution · Print Speed · Print Width · Memory · Communication Interface
Datamax 4308 Printer Datasheet
The Datamax 4308 is a high‑performance 300 dpi label printer designed for precise, high‑speed printing of small tags, high‑quality images, and 2‑D barcodes. Its 32‑bit processor, large memory, and modular design enable easy configuration, upgrades, and reliable operation in harsh environments.
Key features include a dual‑lock mechanism for uniform print‑head pressure, a 5‑button LCD front panel for simple parameter setting, and a robust aluminum chassis. The printer offers parallel, RS‑232, and optional Ethernet interfaces, along with optional accessories such as a rewinder, I/O expansion card, portable controller, and barcode fonts. This manual is written in Chinese.
Covers: Product Features · Technical Specifications · Interface Options · Optional Accessories · Memory
Symbol LS-5800 Barcode Scanner Implementation Manual
The Symbol LS-5800 is a countertop barcode scanner designed for retail and logistics environments. It uses a 670 nm visible laser diode and offers multiple scanning angles for reliable reading of a variety of symbologies.
Key specifications include a compact size of 15.2 × 15.2 × 7.6 cm, 1.1 kg weight, 5 V power supply at 600 mA, and support for UPC/EAN, Code 39, Code 128, and Interleaved 2‑of‑5. The device operates from 0 °C to 40 °C, tolerates storage temperatures from –40 °C to 60 °C, and functions in humidity up to 95 % non‑condensing. This manual is written in Chinese.
Covers: Physical Characteristics · Technical Specifications · Operating Environment
Latest Shanghai条码网 manuals
Shanghai Barcode Network Symbol LS2208AP Barcode scan Implement Manual
User Manual 1 pages · 104 KB · ZHImplementation manual for the Symbol LS2208hAP barcode scanner with specifications, interface options, and programming settings.
Ring 4012PMH Barcode Printer Manual
User Manual 1 pages · 112 KB · ZHThe Ring 4012PMH barcode printer manual provides specifications, printing methods, interfaces, and usage guidelines.
Datamax 4308 Printer Datasheet
Datasheet 1 pages · 108 KB · ZHThe Datamax 4308 printer datasheet provides specifications, features, and interface options for high‑density label and barcode printing.
Symbol LS-5800 Barcode Scanner Implementation Manual
Datasheet 1 pages · 96 KB · ZHThe Symbol LS-5800 barcode scanner implementation manual provides dimensions, power requirements, and technical specifications.
Shanghai Barcode Network TLP 3742 Printer Manual
Product Leaflet 1 pages · 106 KB · ZHThe manual provides specifications and features of the Shanghai Barcode Network TLP 3742 commercial printer.
Casio DT300 Data Collector Product Leaflet
Product Leaflet 2 pages · 123 KB · ZHThe Casio DT300 data collector is a compact, rugged barcode scanner with high‑speed laser scanning, IP54 sealing and long‑life battery.
SATO M10e Barcode Printer Manual
User Manual 2 pages · 111 KB · ZHThe SATO M10e barcode printer manual provides specifications, operating environment, interfaces, and label options.
SATO M84PRO Barcode Label Printer Manual
User Manual 2 pages · 114 KB · ZHThe SATO M84PRO barcode label printer manual provides specifications, features, and operating instructions for this high‑speed industrial printer.
Symbol PDT-1100 Data Collection Terminal Manual
Product Leaflet 2 pages · 107 KB · ZHThe Symbol PDT-1100 data collection terminal manual provides physical specs, technical features, and operating environment details.
Casio IT-500 Data Collector Manual
User Manual 3 pages · 127 KB · ZHThe Casio IT-500 data collector manual provides specifications, operation instructions, and connectivity options for the handheld device.
Shanghai Barcode Network Symbol PDT-8100 date collect Manual
Shanghai Barcode Network DLL8810-M Barcode Scanner User Manual
User Manual 2 pages · 113 KB · ZHThe manual provides specifications, features, and operating instructions for the Shanghai Barcode Network DLL8810-M laser barcode scanner.
Symbol PPT8800 / PPT8846 Data Collector User Manual
User Manual 2 pages · 106 KB · ZHUser manual for Symbol PPT8800 and PPT8846 data collectors, covering physical specs, operating environment, interfaces and safety certifications.
SATO HT200e Barcode Printer Specification Sheet
Datasheet 2 pages · 102 KB · ZHThe SATO HT200e barcode printer specification sheet lists printing methods, resolution, speed, dimensions, and supported barcode types.
Intermec C4 Barcode Label Printer Manual
Product Leaflet 2 pages · 115 KB · ZHThe Intermec C4 is a compact, high‑resolution barcode label printer with thermal transfer/direct thermal printing and RS‑232/parallel interfaces.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Shanghai条码网 manuals
What is the scan speed of the Symbol LS2208hAP?
The scanner operates at 100 scans per second.
From: Shanghai Barcode Network Symbol LS2208AP Barcode scan Implement Manual
Which interfaces are supported by the LS2208hAP scanner?
It supports USB, RS232, Keyboard Wedge, and other emulation interfaces.
From: Shanghai Barcode Network Symbol LS2208AP Barcode scan Implement Manual
What is the maximum print resolution of the Ring 4012PMH?
The printer provides a resolution of 300 dpi (12 dots per millimeter).
Which communication interfaces are supported?
It supports an RS‑232 interface and a standard parallel port.
What printing methods does the Datamax 4308 support?
It supports thermal transfer printing and optional thermal (direct thermal) printing.
What is the maximum print speed of the Datamax 4308?
The printer can print at up to 8 inches per second (203 mm/s).
