The NWD-455 FlexiDome IP is a well-engineered high-performance 1/3-inch CCD network camera that captures superior image quality at all times. This compact vandal-resistant camera can deliver DVD-quality MPEG-4 video at up to 25 frames (PAL) and 30 frames (NTSC) per second. Network video signals are transmitted over IP networks, where they can be received and displayed by PC Web browsers, viewed or recorded by DiBos hybrid recording systems, or managed as part of VIDOS or BVMS video management systems. In addition, BOSCH Video over IP (BVIP) decoders can decode MPEG4 video streams for viewing on CVBS or VGA monitors. FlexiDome IP features MPEG-4 compression, bandwidth limiting, and multicast capabilities that effectively manage bandwidth and storage requirements while delivering unsurpassed image quality and clarity. Analog video service output and on-screen display (OSD) simplify focus adjustment and network configuration, lowering installation and support costs. Ethernet power (PoE) capability eliminates the need for local AC power, simplifying installation and saving costs.
The NWD-455 FlexiDome IP camera is a high‑performance 1/3‑inch CCD network camera that delivers MPEG‑4 video at 25/30 fps with 4CIF resolution, three‑stream video output, PoE power and star‑light low‑light technology. It includes intelligent functions such as vandal‑tamper detection and optional video motion detection.
The guide provides step‑by‑step instructions for mounting the camera, configuring network parameters via the OSD menu, selecting power sources (PoE, 24 VAC, 12 VDC), and understanding the technical specifications, connectors, and optional accessories. This manual is written in Chinese.
| Image Sensor | 1/3‑inch interlaced CCD |
|---|---|
| Resolution (4CIF) | 704 × 576 (PAL) / 704 × 480 (NTSC) at 25/30 fps |
| Video Compression | MPEG‑4 |
| Power Input | PoE (IEEE 802.3af), 24 VAC (12‑28 VAC), 12 VDC (+11‑+36 VDC) |
The camera can be powered by PoE (IEEE 802.3af), 24 VAC (12‑28 VAC) or 12 VDC (+11 to +36 VDC).
It can simultaneously generate two independent MPEG‑4 streams and one JPEG stream.
Yes, it complies with the IEEE 802.3af PoE standard.
