The VIP X2 Dual-channel Video Encoder is a high-quality MPEG-4 format encoder that supports 4CIF/2CIF/half D1/CIF/QCIF resolutions, saves storage space, is compact and portable, supports multicast and Internet data streams, and has alarm input and relay output, and provides a fast Ethernet interface and serial data port.
The VIP X2 is a dual‑channel video encoder that converts analog video sources to MPEG‑4 streams. Each channel can encode video at up to 30 fps in formats such as D1, 4CIF, 2CIF, CIF and QCIF, and supports both PAL and NTSC (CCIR/EIA) standards. The device is designed for integration with security systems and can be accessed via web browsers or compatible Bosch video management software.
The encoder offers a range of interfaces: 10/100BaseT Ethernet (RJ45) with full/half‑duplex operation, USB, RS‑232/422/485 serial ports, and BNC video inputs with selectable 75 Ω termination. LED indicators show power, Ethernet link, video input status and alarm conditions. Power is supplied from 12‑24 VDC, with a typical consumption of about 10 VA. The unit operates from –40 °C to +40 °C, tolerates 20‑80 % humidity, and complies with CE, UL, FCC and other international standards. This manual is written in Chinese.
| Video format | MPEG‑4 |
|---|---|
| Supported resolutions | 704×576 (D1), 352×288 (CIF), 176×144 (QCIF) and variants |
| Bitrate | 9.6 kbps – 6 Mbps |
| Input voltage | 12‑24 VDC |
| Operating temperature | -40 °C to +40 °C |
The VIP X2 encodes video in the MPEG‑4 format.
It supports D1 (704×576/480), 4CIF, 2CIF, CIF (352×288/240) and QCIF (176×144/120) at 25/30 fps.
It requires a 12‑24 VDC supply and consumes approximately 10 VA of power.
