This document introduces the Bosch Rexroth AG Pneumatics pressure regulating valve, model ED07, with a flow rate of Qn=1300 l/min. It uses electronic and signal connections, and has analog control and CE certification. The product is suitable for compressed air media, with a working temperature range of +5°C to +50°C. Parameters such as inlet pressure, operating voltage, and weight are also provided in the document.
This manual describes the ED07 series pressure regulator valve, including its rated flow of 1300 min, IP65 protection, and operating temperature range of +5 °C to +50 °C. Key mechanical data such as weight (2.05 kg) and supply voltage (24 V) are also listed.
The document contains wiring diagrams, pin assignments, and signal connection details for M12 5‑pin connectors, as well as flow‑characteristic curves for various pressure settings. Installation and adjustment procedures are outlined for proper integration into pneumatic systems. This manual is written in Japanese.
| Rated flow (Qn) | 1300 min |
|---|
The rated flow (Qn) is 1300 min.
