These miniature surface mount MOSFETs utilize a high cell density trench process to provide low rDS(on) and to ensure minimal power loss and heat dissipation. Typical applications are DC-DC converters and power management in portable and battery-powered products such as computers,printers, and cordless telephones.
The document describes the Analog Power AM20P02-99D, a miniature surface-mount P-Channel 20-V MOSFET. It utilizes a high cell density trench process to ensure low on-resistance and minimal power loss. The device is designed for use in DC-DC converters and power management circuits within portable products like computers, printers, and telephones.
| Drain-Source Voltage (VDS) | -20 V |
|---|---|
| Continuous Drain Current (ID) | 17 A |
| Power Dissipation (PD) | 50 W |
| Operating Junction Temperature Range | -55 to 175 °C |
| Package Type | TO-252 Surface Mount |
The maximum continuous drain current is 17 A when the temperature is 25°C.
The maximum power dissipation is 50 W at an ambient temperature of 25°C.
The maximum junction-to-ambient thermal resistance is 50 °C/W.
