Key Features: Low rDS(on) trench technology Low thermal impedance Fast switching speed Typical Applications: White LED boost converters Automotive Systems Industrial DC/DC Conversion Circuits
The Analog Power AM20P02-60D is a P-Channel 20-V MOSFET utilizing High Cell Density trench technology. It is designed for minimal power loss and is ideal for power management circuitry in portable and battery-powered products, such as computers, printers, and telecommunication systems. The device features a miniature TO-252 surface mount package to save board space while offering high power and current handling capability.
| Drain-Source Voltage | -20 V |
|---|---|
| Operating Junction Temperature Range | -55 to 175 °C |
| Package Type | TO-252 |
The maximum operating junction and storage temperature range is from -55 to 175 °C.
The maximum continuous drain current is 24 A when the temperature is 25°C.
The maximum power dissipation is 50 W at a temperature of 25°C.
The operating junction and storage temperature range is from -55 to 175 °C.
