Key Features: Low rDS(on) trench technology Low thermal impedance Fast switching speed Typical Applications: PoE Power Sourcing Equipment PoE Powered Devices Telecom DC/DC converters White LED boost converters
The Analog Power AM20N10-250D is an N-Channel 100-V MOSFET featuring low rDS(on) trench technology and fast switching speed. It is designed for applications such as PoE power sourcing equipment, PoE powered devices, telecom DC/DC converters, and white LED boost converters. The device operates with a maximum junction temperature of 175°C and is available in a To-252 package.
| Drain-Source Voltage | 100 V |
|---|---|
| Continuous Drain Current | 11 A |
| Power Dissipation | 50 W |
| Operating Junction Temperature Range | -55 to 175 °C |
| Maximum Junction-to-Ambient Thermal Resistance | 40 °C/W |
| On-State Drain Current | 34 A |
| Drain-Source On-Resistance | 355 mΩ |
The device is suitable for PoE Power Sourcing Equipment, PoE Powered Devices, Telecom DC/DC converters, and White LED boost converters.
The maximum operating junction and storage temperature range is from -55 to 175 °C.
