XLSEMI XL7015 Manuals

ManualLib has 4 documents for the XLSEMI XL7015 (DC/DC Converter): 4 datasheets. Every file can be read online or downloaded as a PDF for free.

Datasheet 4

Key facts

Brand
Xlsemi
Model
XL7015
Industry
Electronics
Documents
4
Languages
EN · ZH
Last added
2026-10-28

Start here

XLSEMI XL7015 0.8A 150kHz 80V Buck DC to DC Converter Datasheet

XLSEMI XL7015 0.8A 150kHz 80V Buck DC to DC Converter Datasheet

Datasheet 10 pages · 521 KB · EN

The XLSEMI XL7015 is a 150kHz fixed frequency PWM buck (step-down) DC/DC converter designed to drive a 0.8A load with high efficiency and low ripple. It features a wide input voltage range of 5V to 80V and an adjustable output voltage from 1.25V to 20V. The device includes an internal high-voltage power transistor, thermal shutdown, and output short protection functions.

Read online

XLSEMI XL7015 specifications

Input Voltage5V to 80V
Output Voltage1.25V to 20V
Switching Frequency150kHz
Maximum Output Current0.8A
Maximum Duty Cycle100%
Package TypeTO252-5L
Maximum Junction Temperature150°C

Source: XLSEMI XL7015 0.8A 150kHz 80V Buck DC to DC Converter Datasheet

All XLSEMI XL7015 documents by type

Questions answered in these manuals

What is the switching frequency of the XL7015?

The XL7015 operates at a fixed switching frequency of 150kHz.

From: XLSEMI XL7015 0.8A 150kHz 80V Buck DC to DC Converter Datasheet

What is the recommended output power limit?

The manufacturer recommends an output power of less than 7W.

From: XLSEMI XL7015 0.8A 150kHz 80V Buck DC to DC Converter Datasheet

What is the maximum input voltage for the XL7015?

The maximum input voltage is 100V.

From: XLSEMI XL7015 0.8A 150KHz 100V Buck DC to DC Converter Datasheet

What is the recommended maximum output current at 48V input and 5V output?

The recommended maximum output current is 0.6A.

From: XLSEMI XL7015 0.8A 150KHz 100V Buck DC to DC Converter Datasheet

What is the recommended maximum output current for a 48V input at 15V output?

The recommended maximum output current is 0.4A.

From: XLSEMI XL7015 0.8A 150KHz 100V Buck DC-DC Converter Datasheet

Does the XL7015 include built-in protection features?

Yes, it includes thermal shutdown, current limiting, and output short-circuit protection.

From: XLSEMI XL7015 0.8A 150KHz 100V Buck DC-DC Converter Datasheet
