XLSEMI XL4001 Manuals

ManualLib has 3 documents for the XLSEMI XL4001 (DC/DC Converter): 2 user manuals, 1 datasheet. Every file can be read online or downloaded as a PDF for free.

User Manual 2Datasheet 1

Key facts

Brand
Xlsemi
Model
XL4001
Industry
Electronics
Documents
3
Languages
ZH
Last added
2026-10-21

Start here

XLSEMI XL4001 DEMO Board User Manual

XLSEMI XL4001 DEMO Board User Manual

User Manual 5 pages · 521 KB · ZH

The document is a user manual for the XLSEMI XL4001 DEMO board. This demonstration board utilizes the XL4001 switch-mode buck DC-DC converter chip, designed specifically for automotive charging applications requiring an input voltage range of DC8V to 40V and a regulated output of 5V at up to 1A. This manual is written in Chinese.

Read online

XLSEMI XL4001 specifications

Input Voltage Range4.5V to 40V
Output Voltage Range1.235V to 37V
Maximum Output Current2A
Switching Frequency150KHz
Minimum Voltage Drop1.5V
Feedback Voltage1.235V
Package TypeSOP8-EP
Operating Junction Temperature-40 to 125 C

Source: XLSEMI XL4001 150KHz 40V 2A Buck DC-DC Converter Datasheet

All XLSEMI XL4001 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Datasheet 1

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What type of diode is recommended for the application?

The manual recommends using a Schottky diode, such as SS34.

From: XLSEMI XL4001 DEMO Board User Manual

What is the maximum output current of the XL4001 demo board?

The maximum output current is 1A.

From: XLSEMI XL4001 DEMO Board User Manual

What is the feedback reference voltage?

The feedback reference voltage is 1.235V, detected through an external resistor divider network.

From: XLSEMI XL4001 150KHz 40V 2A Buck DC-DC Converter Datasheet

What is the fixed switching frequency of the XL4001?

The device operates at a fixed switching frequency of 150KHz.

From: XLSEMI XL4001 150KHz 40V 2A Buck DC-DC Converter Datasheet

What is the input voltage range for the XL4001 DEMO board?

The board supports an input voltage range of DC 8V to 40V.

From: XLSEMI XL4001 DEMO Board User Manual

What is the maximum output current of the board?

The maximum output current is 1A.

From: XLSEMI XL4001 DEMO Board User Manual
