Siemens 3RW34 Soft Starter User Manual
User Manual 47 pages · 701 KB · EN
This manual covers the installation and wiring of the Siemens 3RW34 soft starter, including safety precautions and connection diagrams. It explains how to configure parameters, start and stop the device, and adjust settings for optimal motor control.
The document also contains fault diagnosis tables, technical data such as nominal voltage ratings, and a parts list for service and maintenance. Reference tables and diagrams help technicians troubleshoot and maintain the equipment efficiently.
Siemens 3RW34 specifications
| Maximum output current (24 VDC) | 0.5 A |
|---|---|
| Maximum output current (120 VAC / 230 VAC) | 1.0 A |
| Contact rating (make/break) | 10 A / 1 A |
| Insulation voltage (load side) | 1500 VAC AC |
All Siemens 3RW34 documents by type
User Manual 2
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the nominal voltage of the Siemens 3RW34 soft starter?
The manual lists a nominal voltage of 400 V (and also a version rated at 575 V).
What is the maximum output current when the controller is powered from 24 VDC?
The maximum output current is 0.5 A.
