Key facts
- Brand
- Panasonic
- Model
- EXC28CG
- Documents
- 2
- Languages
- ZH
- Last added
- 2011-10-03
Start here
Panasonic EXC28CG Array Common-Mode Noise Filter Manual
The EXC28CG array common‑mode noise filter is a compact, thin‑profile device with two built‑in filter channels, designed for HDMI‑equipped equipment such as TVs, set‑top boxes, DVD players and digital camcorders, as well as for computers and HDDs with SATA interfaces. It offers high‑frequency signal integrity by suppressing common‑mode noise, improving eye‑diagram compliance and reducing radiation.
The manual lists electrical characteristics (e.g., 24 Ω or 90 Ω impedance at 100 MHz, +25 VDC rated voltage, and temperature range –40 °C to +85 °C), packaging instructions, solder‑pad design recommendations, and safety notes. It also includes impedance‑vs‑frequency graphs and references to detailed sections for mounting and testing. This manual is written in Chinese.
All Panasonic EXC28CG documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What devices can use the EXC28CG filter?
It is used in HDMI‑equipped devices such as TVs, set‑top boxes, DVD players, digital camcorders, as well as computers and HDDs with SATA interfaces.
From: Panasonic EXC28CG Array Common-Mode Noise Filter Manual
What is the operating temperature range of the EXC28CG filter?
The filter operates from –40 °C up to +85 °C.
From: Panasonic EXC28CG Array Common-Mode Noise Filter Manual
What is the operating temperature range of the EXC28CG filter?
The filter operates from –40 °C up to +85 °C.
From: Panasonic EXC28CG Array Common-Mode Noise Filter Datasheet
