Datalogic PowerScan D8530 Manuals

ManualLib has 2 documents for the Datalogic PowerScan D8530 (Other Electronics): 1 user manual, 1 quick start guide. Every file can be read online or downloaded as a PDF for free.

User Manual 1Quick Start Guide 1

Key facts

Model
PowerScan D8530
Documents
2
Languages
EN
Last added
2012-08-06

Start here

Datalogic PowerScan D8530 Family Quick Reference Guide

Datalogic PowerScan D8530 Family Quick Reference Guide

Quick Start Guide 32 pages · 549 KB · EN

The PowerScan D8530 family are rugged, omni-directional handheld readers that decode all major 1D and 2D barcodes, capture images, support autoscanning, and allow firmware upgrades via flash memory. They operate in commercial, industrial, and front-office environments.

Setup involves connecting the correct interface cable (RS-232, Wedge, or USB), reading the appropriate interface selection code, and using default settings. The USB interface is compatible with Windows 98 and later, IBM POS for Windows, Mac OS 8.0 and later, and the 4960 Operating System. Green LED indicators signal power-on and good reads, while a beeper provides audible feedback.

Read online

Datalogic PowerScan D8530 specifications

Interface OptionsRS-232, Wedge, USB
USB CompatibilityWindows 98 and later, IBM POS for Windows, Mac OS 8.0 and later, 4960 Operating System
Decoding Capabilities1D linear, 2D stacked (PDF417), 2D matrix (DataMatrix), postal codes (PLANET)
ImagingCaptures entire images or image portions
AutoscanningContinuous scanning monitoring central zone
Flash MemoryFirmware upgrades for new symbologies and algorithms
LED IndicatorsGreen LED for power-on and good read
BeeperGood/wrong read and error signals
Good-Read SpotGreen spot projected on successful read

Source: Datalogic PowerScan D8530 Family Quick Reference Guide

All Datalogic PowerScan D8530 documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Quick Start Guide 1

The shortest path to a working setup, usually only a few pages.

Questions answered in these manuals

What class of laser product is the aiming system?

The aiming system is a Class 2 laser product.

From: Datalogic PowerScan D8530 Barcode Reader Reference Manual

What class of LED product is the illuminator?

The illuminator is a Class 1 LED product.

From: Datalogic PowerScan D8530 Barcode Reader Reference Manual

What interfaces does the PowerScan D8530 support?

The scanner supports RS-232, Wedge, and USB interfaces.

From: Datalogic PowerScan D8530 Family Quick Reference Guide

Which operating systems are compatible with the USB interface?

Windows 98 and later, IBM POS for Windows, Mac OS 8.0 and later, and the 4960 Operating System.

From: Datalogic PowerScan D8530 Family Quick Reference Guide
