This manual provides instructions for setting, wiring, connecting, and verifying the operation of Yaskawa Sigma-V series servo motors and servo units.
This manual covers the configuration, wiring, and connection procedures for the Yaskawa Sigma-V series servo system, including models SGMJV, SGMAV, SGMGV, SGMCS, and SGDV. It details how to set up the servo motor and servo unit, perform wiring according to specific rules, and conduct single-unit operation checks (trial runs).
The document includes essential safety precautions regarding handling, installation, and operation. It explains specific terms used in the manual, such as the notation for inverted signals, and outlines the necessary steps to ensure safe operation and prevent equipment damage or personal injury during setup and maintenance. This manual is written in Chinese.
The manual covers the SGMJV, SGMAV, SGMGV, and SGMCS servo motors, as well as the SGDV servo amplifier.
The symbol indicating a risk of death or serious injury is the exclamation mark inside a triangle (⚠).
The maximum recommended length for the encoder cable is 20 meters.
