The Yaskawa H1000 inverter manual provides specifications, safety features, operation instructions and programming guidance for heavy‑duty industrial…
The H1000 series is a heavy‑duty / super‑heavy‑duty inverter designed for high‑output, high‑performance motor drive in demanding industrial environments. It supports both induction and synchronous (IPM) motors, offering high starting torque even without sensors.
The manual covers product features, technical specifications, installation methods, safety functions, visual programming with DriveWorksEZ, communication options, and maintenance procedures, helping users select the right configuration and quickly set up the inverter for various mechanical applications. This manual is written in Chinese.
| Capacity range (kW) | 0.4 – 560 |
|---|---|
| Rated voltage | 400 V |
| Overload capacity | 200 % for 3 seconds |
Programming is done with the visual programming tool DriveWorksEZ via a USB port, allowing drag‑and‑drop configuration of parameters and custom actions.
Yes, the inverter features an application‑selection function that automatically sets optimal parameters based on the chosen mechanical use, reducing setup time.
