Xinje TP/TH/TG/TE/RT/MTG/CCSG Series HMI Hardware User Manual

About this manual

This document serves as the hardware user manual for the Xinje TP/TH/TG/TE/RT/MTG/CCSG series of Human Machine Interfaces (HMI). It provides detailed product overviews, including product characteristics, model naming conventions, and specific specifications for each series.

The manual covers general specifications such as electrical characteristics, environmental requirements, and interface descriptions. It also includes detailed sections on product dimensions, installation guidelines, and usage environments for various models within the series. This manual is written in Chinese.

What's inside

• TP Series Product Overview
• TH Series Product Overview
• TG Series Product Overview
• TE Series Product Overview
• RT Series Product Overview
• MTG Series Product Overview
• CCSG Series Product Overview
• General Specifications
• Product Dimensions and Installation
• Interface Descriptions

Frequently asked questions

What is the required input voltage for the TG series HMI?

The device requires a DC power supply of +24V with a range between 22V and 26V.

How should the DC power connections be made to the TG series HMI?

Connect the positive terminal of the DC source to the '+24V' end and the negative terminal to the '0V' end.

What happens if high voltage or AC power is connected to the HMI power input?

Connecting high voltage or AC power will cause the device to fail and may result in electric shock, injury, death, or equipment damage.
