Xinje TouchWin Editor Software User Manual for TP/TH/TG/TE/TN/XMH/XME/ZG Series

About this manual

This user manual introduces the usage methods for the Xinje TouchWin editor software, which is designed for the TP/TH/TG/TE/TN/XMH/XME/ZG series Human Machine Interfaces (HMI). The document provides comprehensive guidance on software installation and uninstallation, project creation, and offline or online simulation. This manual is written in Chinese.

What's inside

• TouchWin Editor Software Installation
• Simple Project Creation
• Screen Editing
• Components
• Internal Objects
• Special Features
• Function Blocks
• Troubleshooting

Specifications

Frequently asked questions

Does the software support Traditional Chinese input?

Yes, the software has a Traditional Chinese version and supports input of Traditional Chinese characters.

Can programs from different series be converted?

Programs from MP/XMH/XME series cannot be mutually converted with TP/TH/TG/TE/TN/ZG series programs.

How to switch the HMI download port to communication mode?

Users need to switch the HMI download port to communication mode to enable communication with other devices.

What causes the HMI screen to appear white?

A white screen on the HMI can be caused by specific hardware or software issues requiring troubleshooting.
