This manual explains safety, I/O specs, PLC and HMI functions, and extension options for the Xinje XP/XMP-18 integral industrial controller.
The Xinje XP/XMP-18 series integral industrial controller combines a human‑machine interface and PLC in a compact unit. This operating manual provides the information needed to install, configure, and safely operate the controller.
Key sections cover safety notices, input/output specifications and exterior layout, PLC programming, HMI configuration, and the controller's extension capabilities via BD boards and MA modules.
| Digital input points | 10 points (optical coupling insulation) |
|---|---|
| Digital output points | 8 points (relay/transistor/R&T mixture) |
| Display | 192 × 64 pixel LCD, 3.7 inch |
| Waterproof rating | IP20 |
| Function keys | 26 keys, user‑redefinable |
The controller uses a 192 × 64 pixel LCD with a 3.7‑inch screen.
