Altera Arria II Device Handbook Volume 1: Device Interfaces and Integration

About this manual

This document serves as the first volume of the Arria II device handbook, focusing on device interfaces and integration. It details supported configuration schemes such as Fast Passive Serial (FPP), Active Serial (AS), and Parallel Serial Mode (PS) for both Arria II GX and GZ families. This manual is written in Chinese.

What's inside

• Configuration Functions
• Power-On Reset Circuit
• Configuration Pin Power
• VCCPD Programming Power
• Design Security
• Remote System Update

Frequently asked questions

What voltage levels are supported for Arria II GX configuration pins?

The supported configuration voltages for Arria II GX devices are 1.8, 2.5, 3.0 and 3.3 V.

What voltage levels are supported for Arria II GZ configuration pins?

The supported configuration voltages for Arria II GZ devices are 1.8, 2.5 and 3.0 V.

How long does it take for the power to rise during fast POR time?

During fast POR time, the power must rise from 0 V to the required voltage level within 4 ms.
