This manual describes the Alinx ACU2CG core board based on Xilinx Zynq UltraScale+ MPSoCs, detailing its hardware architecture and interface specifications.
The Alinx ACU2CG is a development platform core board designed for secondary development. It features a Xilinx XCZU2CG-1SFVC784 E chip from the Zynq UltraScale+ MPSoCs CG series, integrating 2GB of DDR4 memory and storage solutions including QSPI Flash and eMMC Flash.
The board provides extensive interface expansion capabilities suitable for system integration. Key features include PS-side USB 2.0, Gigabit Ethernet, SD card interfaces, and high-speed MGT transceivers, along with a comprehensive array of PL I/O pins (96 HP I/Os and 84 HD I/Os) optimized for signal integrity. This manual is written in Chinese.
| Processor Core | 2x ARM Cortex-A53 @ 1.2GHz, 2x Cortex-R5 @ 500MHz |
|---|---|
| Memory Capacity | 2GB DDR4 SDRAM |
| DDR4 Speed | 1200 MHz (2400 Mbps) |
| QSPI Flash Size | 256MBit |
| eMMC Flash Size | 8GB |
| Logic Cells | 103K |
| Block RAM | 5.3Mb |
| Board Dimensions | 80*60 mm |
The board uses the Xilinx XCZU2CG-1SFVC784 E chip from the Zynq UltraScale+ MPSoCs CG series.
The DDR4 SDRAM on this board can operate at a maximum speed of 1200 MHz.
Yes, the ZYNQ chip supports 2xUSB3.0 interfaces among its high-speed connections.
