ZYNQ7000 FPGA Core Board AC7Z010 User Manual

This document is the user manual for ZYNQ7000 FPGA Core Board AC7Z010, which describes the features and characteristics of the product, including ZYNQ chip, DDR3 DRAM, QSPI Flash, clock configuration, power supply, etc.


ZYNQ7000 FPGA Core Board AC7Z010 User Manual - cover page
Brand
Alinx
Category
Other Electronics
Document type
User Manual
Language
English
Pages
20
File format
PDF
File size
740 KB
Published
27 December, 2022
Updated
28 September, 2023
MD5 checksum
5E22714A4159534D4FEA49DBD547D660

About this manual

The Alinx AC7Z010 is a ZYNQ FPGA development core board based on the Xilinx XC7Z010-1CLG400I chip. It features an integrated Processing System (PS) with dual ARM Cortex-A9 processors and a Programmable Logic (PL) section containing 28K logic cells. The board is designed to connect with carrier boards via extended board-to-board connectors.

What's inside

  • AC7Z010 Core Board Introduction
  • ZYNQ Chip Specifications
  • DDR3 DRAM Configuration
  • Clock Configuration
  • Power Supply
  • Board Size Dimensions
  • Board to Board Connectors

Specifications

FPGA Chip ModelXC7Z010-1CLG400I
Processor TypeDual ARM Cortex-A9
Logic Cells28K
Block RAM240KB
DDR3 Capacity1GB (two chips)
DDR3 Speed533MHz
Board Dimensions35 * 42 mm

Frequently asked questions

What FPGA chip does the AC7Z010 core board use?

It uses the Xilinx XC7Z010-1CLG400I chip from the ZYNQ7000 series.

What is the total capacity of the DDR3 memory?

The board has a total capacity of 1GB using two Micron chips.

How many logic cells are available on the PL?

The Programmable Logic section contains 28K logic cells.
