Advantech HMI Display User Manual

User manual for Advantech HMI displays covering safety, installation, quick start, and troubleshooting for multiple models.

Advantech HMI Display User Manual - cover page
Brand
Advantech
Document type
User Manual
Language
English
Pages
23
File format
PDF
File size
1.8 MB
Published
29 September, 2026
Updated
29 September, 2026
MD5 checksum
1D8B30006C7359D3489838A60A227277
PDF
Advantech HMI Display User Manual PDF

About this manual

This manual provides safety instructions, terminology, and basic installation guidance for Advantech HMI (Human‑Machine Interface) displays. It explains proper handling, power connection, and environmental precautions to ensure safe operation.

The document also includes quick‑start procedures for various models (e.g., AWS‑8248V, AVg‑8420, TPC‑1560), macro key configuration, troubleshooting tips for display and keyboard issues, and maintenance recommendations such as grounding and cleaning.

What's inside

  • Safety Instructions
  • Common Terminology
  • Display Resolutions
  • Quick Start Procedure
  • Macro Function Keys
  • Troubleshooting
  • Power Grounding
  • Maintenance

Specifications

Touch Screen TypesResistive and Capacitive
Operating EnvironmentDo not use in wet environments

Frequently asked questions

What does HMI stand for?

HMI stands for Human‑Machine Interface, abbreviated from Hunan Nachi ne Interface.
