The Advantech PCI-1203 EtherCAT Master PCI Card User Manual provides product overview, installation, hardware service, programming, and specifications.
This manual covers the Advantech PCI-1203 EtherCAT Master PCI Card, describing its features, EtherCAT functionality, and the Common Motion SDK architecture. It includes sections on product overview, installation procedures, hardware service, EtherCAT utilities, programming guide, and configuration files.
The document also details motion status monitoring, motion functions, DI/O and AI/O control, safety instructions, warranty information, and a comprehensive error‑code list for troubleshooting. This manual is written in Chinese.
| Motion latency | 500 µs |
|---|---|
| I/O latency | 200 µs |
| Digital input ports | 128 ports (128 bytes) |
| Digital output ports | 128 ports (128 bytes) |
| Analog input channels | 128 channels (256 bytes) |
| Analog output channels | 128 channels (256 bytes) |
| Input voltage logic low | 0–5 V (max) |
| Input voltage logic high | 1–6 V (min, 24 V max) |
| Input resistance | 8.4 kΩ |
| Input delay time | 150 µs |
| Isolation protection (input) | 1,000 VDC |
| Output type | Sink, 12–24 VDC |
| Sink current per channel (23 °C) | 300 mA |
| Sink current per channel (60 °C) | 200 mA |
| Switching frequency | 30 kHz @ 24 VDC |
| Surge protection | 10 kV |
Advantech offers a two‑year product warranty from the date of purchase, excluding products serviced by unauthorized personnel.
The card provides 128 digital input ports (128 bytes).
Motion commands have a latency of 500 µs.
