FrSky R9M 2019 Module Instruction Manual

FrSky R9M 2019 (EU) Module Instruction Manual, introduces the module's overview, function buttons, LED indicators, features and specifications.

Brand: FrSky
Document type: User Manual
Language: English
Pages: 2
File format: PDF
File size: 3.2 MB
Published: 15 October, 2023
Updated: 15 October, 2023
Model: R9M 2019
MD5 checksum: 6EC458BACC27DD3ADAD63C702DF4A717
PDF: FrSky R9M 2019 Module Instruction Manual PDF

About this manual

The FrSky R9M 2019 is a long-range RC system module operating at 868MHz. It supports both Telemetry mode (25mW output) and No Telemetry modes (200mW or 500mW output). The device features an 8-channel or 16-channel output capability and utilizes Smart Port for high-speed digital data transmission.

What's inside

Introduction
Overview
Specifications
Binding Procedure
Failsafe Mode
Range Check

Specifications

Operating Frequency	868MHz
Voltage Range	DC 6.5V~13V
Telemetry Interface	Smart Port
Modulations	PXX or CPPM

Frequently asked questions

How do I switch between Telemetry and No Telemetry modes?

Switch the mode using Switch 1 and Switch 2 on the module before binding. The LED blink pattern indicates the selected power level.

What are the available failsafe modes?

The three available failsafe modes are No Pulse, Hold, and Custom.
