FrSky TANDEM XE is FrSky's latest flight controller, supporting simultaneous work on the 2.4G and 900M dual bands. It adopts a large screen design, and is equipped with 2.4G and 900M dual-band modules. It also has headphone jacks, Micro SD card jacks, training ports, smart ports and other rich interfaces
The FrSky TANDEM XE is a large form factor tray radio featuring a dual-screen design with a 4.3-inch main touch-screen and a 2.4-inch top color screen. It utilizes the ETHOS operating system and includes a built-in TD-ISRM internal RF module supporting 24 channels and dual-band 2.4G & 900M technologies.
| Dimension | 345*262*82mm (L*W*H) |
|---|---|
| Weight | 1357g (Battery Excl.) / 1492g (Battery Incl.) |
| Operating System | ETHOS |
| Number of Channels | 24 channels |
| Operating Voltage Range | 6.5 ~ 8.4V (2S Li-battery) |
| Operating Temperature | -10°C~60°C (14°F~140°F) |
| Built-in Flash Storage | 8GB |
| Main Display Resolution | 800×480 |
| Top Display Resolution | 320×240 |
The available failsafe modes are No Pulse, Hold, and Custom mode.
You must wait 9 seconds for the failsafe to take effect after selecting the mode.
Under normal circumstances, the RSSI at 150m should be about 45-50.
