TD R10 receiver is a dual-band receiver from FrSky, working simultaneously in both 900MHz and 2.4Ghz frequencies, providing low latency signal and long-range control, also benefits from the enhanced level of high reliability and anti-interference performance.
The FrSky TD R10 is a Tandem dual-band receiver that operates simultaneously at 2.4GHz and 900MHz frequencies. It utilizes a triple antenna design for wide coverage and includes a built-in black box module to record flight data such as RSSI, voltage, and reset cases.
| Frequency | 2.4GHz & 900MHz |
|---|---|
| Dimension | 46.5*26.3*14.7mm (L*W*H) |
| Weight | 16.6g |
| Operating Voltage | 3.5-10v DC |
| Operating Current | <180mA@5V |
The 10 channel ports can be assigned as PWM, SBUS, FBUS, or S.Port.
The receiver offers a long control range of up to 50KM - 100KM.
Firmware updates are performed via Over-The-Air (OTA) using the File manager and Flash RX by int.OTA function.
