The document is an official guide for the TCI MotorGuard™ KMG High Performance Output Filter. It provides comprehensive instructions for qualified electricians regarding the safe installation, wiring, commissioning, and daily operation of the device when connected to variable frequency drives (VFDs) and AC motors.
Key sections include safety warnings, pre-installation planning, detailed mounting and wiring guidelines, operational adjustments, periodic maintenance schedules, troubleshooting procedures, and replacement parts information. The manual also contains warranty details from Trans-Coil, Inc., storage instructions, and technical specifications.
The MotorGuard is designed to connect to the output terminals of a variable frequency drive (VFD).
You must wait 5 minutes for capacitors to discharge after switching off the power.
