Panasonic WJBP65E01 Manual

Network Board WJ-PB65E01 is designed for the connection with Central Processing Unit WJ-MPU955A and system expansion of Matrix Switcher WJ-SX650 Series.

Brand: Panasonic
Category: Other
Document type: User Manual
Language: English
Pages: 8
File format: PDF
File size: 923 KB
Published: 08 August, 2012
Updated: 30 September, 2023
Model: WJ-PB65E01
MD5 checksum: D77B621AD4522783545F43E2E3A50537
PDF: Panasonic WJBP65E01 Manual PDF

About this manual

This manual provides operating instructions for the Panasonic WJ-PB65E01 Network Board, designed for use with the Central Processing Unit WJ-MPU955A and the WJ-SX650 Series Matrix Switcher. It details the board's functions, including Ethernet connectivity, alarm outputs, and video signal loop-through capabilities.

What's inside

Precautions
Board Mounting Procedure
Firmware Update
System Requirements
Installation and Uninstallation
PC Connection

Specifications

Maximum Cameras	512
Maximum Monitors	64
Network Interface	10/100BASE-T
Serial Interface	9-pin D-sub connector

Frequently asked questions

What are the default login credentials for the firmware update software?

The factory default user name is 'user' and the password is '12345'.

Which operating systems are supported for the firmware update tool?

The tool supports Microsoft Windows 2000 Professional SP4, Windows XP Professional SP2, and Windows XP Home Edition SP2.
