This document provides ordering information for the MP510A, MP530A series of multi-purpose meters and accessories produced by Extech Instruments Corporation. These instruments feature high accuracy, wide bandwidth, rugged design, and can be connected to a computer for data collection and analysis.
This document is a product datasheet for the EXTECH MP510A MultiPro Series Professional MultiMeter. It highlights the instrument's high-performance autoranging capabilities, True RMS measurement for distorted waveforms, and rugged design with a protective halster and water-resistant housing. The MP510A features a backlit 5000 count LCD display and an optically isolated RS-232 PC interface compatible with various Windows operating systems.
| Basic DC Voltage Accuracy | 0.08% |
|---|---|
| AC Voltage Bandwidth | 40Hz to 20kHz |
| Display Resolution | 5000 count |
| Frequency Range | 5Hz to 125kHz |
| Temperature Range | -8 to 1832°F (50 to 1000°C) |
| Dimensions | 7.32 x 8.42 x 1.39" |
The instrument measures AC/DC voltage and current, resistance, frequency, capacitance, diode, and continuity.
The unit measures 8.42 inches wide.
The maximum DC voltage range is 1000V.
