EverFocus EPTZ3100/EPTZ3100I Speed Dome User Manual

This manual introduces the features and characteristics of Speed Dome EPTZ3100/EPTZ3100I, including product overview, specifications, features, installation, initial setup, bracket and adapter installation, camera setup menu, etc.

Brand: EverFocus
Category: Monitoring Equipment
Document type: User Manual
Language: Chinese
Pages: 75
File format: PDF
File size: 1.7 MB
Published: 09 July, 2012
Updated: 30 September, 2023
MD5 checksum: 9DDB47A169708567018B3D71471CE7B0
PDF: EverFocus EPTZ3100/EPTZ3100I Speed Dome User Manual PDF

About this manual

The document is a comprehensive user guide for the EverFocus EPTZ3100 (outdoor) and EPTZ3100I (indoor) Speed Dome series. It details product features such as high-speed scanning, wide dynamic range, and true day/night capabilities using an ICR filter. The manual provides instructions on setting up the camera via menu structures for video settings, positions, alarms, and system configurations. This manual is written in Chinese.

What's inside

EPTZ3100/EPTZ3100I Overview
Specifications
Features
Quick Operation Guide
Installation Requirements
Bracket Installation
Camera Setup Menu
Alarm Linking
Tour Mode
Other Operations

Specifications

Pickup Device	1/4" CCD
Horizontal Resolution	520 TV Lines
Zoom Ratio	240x max.
Power Consumption	21W Max
Preset Positions	192 positions

Frequently asked questions

What is the difference between EPTZ3100 and EPTZ3100I?

EPTZ3100 is an outdoor type, whereas EPTZ3100I is an indoor type.

How many alarm inputs and outputs does the camera have?

The speed dome has 4 alarm inputs and 2 alarm outputs.
