Specifications for the SC105.5. series Schottky diodes, including dimensions, thickness, current, and voltage.
This document is a datasheet for the International Rectifier SC105.....5. Series Schottky dies. It provides detailed electrical characteristics for various device types, including maximum reverse voltage, forward current, and forward voltage drop at specific temperatures.
The document also includes mechanical data specifying metal thickness, bondability, and sowing recommendations. Additionally, it outlines ordering information, packaging styles such as wafer in box or tape and reel, and storage environment requirements.
| Package Style | TO-220, TO-247 |
|---|---|
| Die Thickness | 10 mils |
| Shelf Life (Nitrogen) | 2 years |
| Shelf Life (Normal Atmosphere) | six months |
| Minimum Order Quantity (Tape & Reel) | 8,000 |
The recommended blade is SEMITEC $1025 QS00 Blade.
All dimensions are shown in Mils.
