Agilent 3000 Refinery Gas Analyzer (RGA) is a four-channel analyzer weighing 11.2 kg (24.8 lbs) and measuring 15.5 cm high x 47.2 cm wide x 42.0 cm deep (6.1 x 18.5 x 16.5 in.). It can be operated in an environment with a temperature range of 0 °C to 50 °C, relative humidity of 5 to 95% (non-condensing) and an altitude of up to 15,000 ft (4,572 m). It is compatible with mixtures that are in a gaseous phase at STP and typically used for compounds with BP<250 °C. Maximum sample pressure is less than 30 psig and recommended sample pressure is 5-10 psig.
This document provides technical specifications for the Agilent 3000 Refinery Gas Analyzer (RGA). The unit weighs 11.2 kg and measures 15.5 cm high x 47.2 cm wide x 42.0 cm deep. It is designed for indoor or enclosed use with an operating temperature range of 0 °C to 50 °C and relative humidity of 5 to 95% non-condensing.
| Weight | 11.2 kg (24.8 Ibs) |
|---|---|
| Dimensions | 15.5 cm high x 47.2 cm wide x 42.0 cm deep |
| Operating Temperature Range | 0 °C to 50 °C |
| Relative Humidity | 5 to 95% non-condensing |
| Maximum Altitude | 15,000 ft (4,572 m) |
| Power Supply Input | 100/240 Vac, 50/60 Hz, 250 VA |
| Power Supply Output | 24 Vdc at 5.4 Amps, 130 Watts |
| Minimum Detection Level | <10—20 ppm |
| Linear Dynamic Range | 10° + 10% |
| Repeatability | <0.5% RSD |
The operating temperature range is 0 °C to 50 °C.
The maximum sample pressure is less than 30 psig.
Channel A uses Argon, while Channels B, C, and D use Helium.
