The DS90C365A is a programmable LVDS transmitter designed for 18-bit flat panel display links with a transmission rate of 85 MHz. It converts 21 bits of LVCMOS/LVTTL data into four LVDS data streams and transmits a phase-locked transmit clock in parallel with the data streams over the fourth LVDS link. The transmitter can be triggered by either rising or falling edge strobe. This product is ideal for solving EMI and cable size problems associated with wide, high-speed TTL interfaces, and it supports spread spectrum clocking.
The DS90C365A is a +3.3V programmable LVDS transmitter designed for 18-bit flat panel display links with a maximum frequency of 85 MHz. It serves as a pin-to-pin compatible replacement for the DS90C363, DS90C363A, and DS90C365 models, offering additional features such as Spread Spectrum Clocking support and an Input Clock Detection feature.
| Supply Voltage (Vcc) | 3.0V to 3.6V (Typical 3.3V) |
|---|---|
| Maximum Clock Frequency | 85 MHz |
| LVDS Output Swing | 345 mV (Typical) |
| Power-Down Current | 150 pA (Typical) |
| Package Type | 48-lead TSSOP |
The recommended supply voltage is 3.3V.
The transmitter supports an input clock frequency of up to 85 MHz.
